21999-0390-Z-ED Tsunami Oil Coalescing Filter Grade Z Element – w/ Electronic Drain – 20 Series – ¼” In/out – 20 SCFM

$250.80

Free Shipping Over $100 On This Product
Purchase this product now and earn 502 Points!*
Typical lead time is 7-10 business days
SKU: 21999‑0390‑Z‑ED Categories: ,

Description

Tsunami Oil Coalescing Filters protect your equipment and delicate instruments from dirt, water and oils found in compressed air systems. This will also eliminate fish eye found in paint jobs. Tsunami coalescing filters remove these contaminates at a very high efficiency – up to 99.99% for .01 micron particles and droplets. Air flows from inside the element out. Liquid will release from the filter and drop down to the sump where an electronic drain will eject the collected liquid on a set schedule. We oversize our elements which reduces pressure drop and gives longer life. Typical pressure drops are 1 psig dry and 2 psig wet.

Tsunami Youtube Playlist
Related PDFs

Specifications

Weight 2 lbs
Dimensions 12 × 4 × 4 in
Flow Rating

Port Size

1/4 in. NPT

ISO Class

<1

Micron Rating

.001 Microns

Oily Carry Over PPM

.001

Max Pressure

250 psi

Drain Type

Electronic

Max Temperature

150 F

Nominal Length

12 in.

Nominal Width

2 in.
