Standard Housings

Standard Pentair/Ametek Housings
All of these Filter Housings include a Mounting Braket Head and a Pressure Relief Button. We could sell the Housings without them, however it makes filter change out easier.
150067150067 150069150069 150239150239 150067150235
Max Flow Rate through Housing 10 gpm 10 gpm 20 gpm 40 gpm
Max. Pressure 125 psi 125 psi 100 psi (6.9 bar) 90 psi (6.2 bar)
Max. Temperature 125°F/51.7°C 125°F/51.7°C 100°F/37.8°C 100°F/37.8°C
Change Out Wrench # 150295 150295 150296 SH144368
Mounting Braket # 150578 150578 150061 150061
Replacement O-Ring # 151120 151120 151122 151122
Cartridge Dimensions Diameter: 2.5″-2.75″
Length: 9.75″-10″
Diameter: 2.5″-2.75″
Length: 19.5″-20″
Diameter: 4.0″-4.5″
Length: 9.88″-10″
Diameter: 4.0″-4.5″
Length: 20″
Correct Fit Carbon Filters 2.5″ x 10″ Filters 2.5″ x 20″ Filters 4″ x 10″ Filters 4.5″ x 20″ Filters
Correct Fit Sediment Filters 2.5″ x 10″ Filters  2.5″ x 20″ Filters 4″ x 10″ Filters 4.5″ x 20″ Filters
Specialty Filters  2.5″ x 10″ Filters 2.5″ x 20″ Filters 4″ x 10″ Filters 4.5″ x 20″ Filters
